MINI Cooper II facelift (2010-2015) oil pr sw Wiring diagram
This page shows the only wiring diagram for the component.oil pr sw, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil pr sw (1 of 1)
BLK WIRE
BLU WIRE
COOLANT PUMP
CRANKSHAFT SENSOR
DME CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
FUEL INJECTION 1
FUEL INJECTION 2
FUEL INJECTION 3
FUEL INJECTION 4
FUIL INJ
GRN WIRE
GRY WIRE
IGN COIL
IGN COIL SIG
INT VLVE
MASS METR
NCA WIRE
OIL PR SW
OIL PRESSURE SWITCH
ORG/ WIRE
OXYGEN SENSOR AFTER CATALYTIC CONVERTER
OXYGEN SENSOR BEFORE CATALYTIC CONVERTER
RAIL PR SENS
RAIL PRESSURE SENSOR
SENS
SENS SIG
SIG
THROTTLE VLVE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo, jcw (3 of 4) -> OIL PR SW
