MINI Cooper II facelift (2010-2015) most-bus connector Wiring diagram
This page shows the only wiring diagram for the component.most-bus connector, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram most-bus connector (1 of 1)
CCC/ M-ASK
CCC/M-ASK
CD CHANGER
COMBOX
COMBOX (UNDER FRONT PASSENGER'S SEAT)
DIGITAL TUNER US
GRN WIRE
INTERFACE BOX HIGH
MOST BUS CONNECTOR (UNDER RIGHT END OF DASH)
MOST-BUS CONNECTOR
RADIO
SATELLITE RECEIVER
ULF- SBX-H
ULF-SBX
W/ COMBOX
W/ ULF-SBX INTERFACE BOX W/ ULF-SBX-H
W/ ULF-SBX INTERFACE BOX W/ ULF-SBX-H INTERFACE BOX HIGH
Go to component -> Most data bus circuit -> MOST-BUS CONNECTOR
