MINI Cooper II facelift (2010-2015) (left side of left Wiring diagram
This page shows the only wiring diagram for the component.(left side of left, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (left side of left (1 of 1)
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CONVERTIBLE EXCEPT CONVERTIBLE CLUBMAN W/O
EXCEPT CLUBMAN, CLUBMAN W/O RAPID CARGO CLUBMAN W/ RAPID CARGO
EXCEPT CONVERTIBLE
FOOTWELL MODULE (LEFT SIDE OF LEFT FOOTWELL)
FOOTWELL)
FRONT INTERIOR LIGHT
FUSE
GLOVE COMPARTMENT LIGHT
GRY WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
JUNCTION BOX (RIGHT KICK PANEL)
LEFT REAR INTERIOR LIGHT
LUGGAGE COMPARTMENT LIGHT
RAPID CARGO
REAR INTERIOR LIGHT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT REAR INTERIOR LIGHT
RIGHT SPLIT DOOR CENTRAL LOCKING DRIVE (CLUBMAN) (ON RIGHT SPLIT DOOR)
ROOF OPERATING UNIT
TRUNK LID CENTRAL LOCKING DRIVE (EXCEPT CLUBMAN)
VIO WIRE
VIO/GRY WIRE
VIO/YEL WIRE
W/ REAR INTERIOR LIGHT W/O REAR INTERIOR LIGHT
YEL WIRE
Go to component -> Courtesy lamps circuit, without interior lights package -> (LEFT SIDE OF LEFT
