MINI Cooper II facelift (2010-2015) late production early production Wiring diagram
This page shows the only wiring diagram for the component.late production early production, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram late production early production (1 of 1)
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/YEL WIRE
FUSE
FUSE 47
HORN
HORN (FRONT OF RIGHT FRONT WHEEL)
HORN 2
HORN 2 (FRONT OF RIGHT FRONT WHEEL)
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
JUNCTION BOX
JUNCTION BOX (RIGHT KICK PANEL)
LATE PRODUCTION EARLY PRODUCTION
RED/BLU WIRE
STEERING COLUMN SWITCH CLUSTER
W/ INDIVIDUAL HORN
W/ TWIN HORN
Go to component -> Horn circuit -> LATE PRODUCTION EARLY PRODUCTION
