MINI Cooper II facelift (2010-2015) junction box (right kick Wiring diagram
This page shows the only wiring diagram for the component.junction box (right kick, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram junction box (right kick (1 of 1)
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE PANEL
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED
JUNCTION BOX
JUNCTION BOX (RIGHT KICK
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR CENTER ULTRASONIC SENSOR (REAR BUMPER)
LEFT REAR ULTRASONIC SENSOR
LEFT REAR ULTRASONIC SENSOR (REAR BUMPER)
ORG/GRN WIRE
PARK DISTANCE CONTROL UNIT (PDC)
PARK DISTANCE CONTROL UNIT (PDC) (RIGHT SIDE OF REAR COMPT)
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR CENTER ULTRASONIC SENSOR (REAR BUMPER)
RIGHT REAR ULTRASONIC SENSOR
RIGHT REAR ULTRASONIC SENSOR (REAR BUMPER)
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Parking assistant circuit -> JUNCTION BOX (RIGHT KICK
