MINI Cooper II facelift (2010-2015) headlight cleaning system relay Wiring diagrams
This page contains all the electrical diagrams for the component. headlight cleaning system relay, in which he is found in the car MINI Cooper II facelift (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram headlight cleaning system relay (1 of 2)
Go to component -> Headlamp washer circuit -> HEADLIGHT CLEANING SYSTEM RELAY
Wiring diagram headlight cleaning system relay (2 of 2)
1.6L
1.6L TURBO 1.6L
A/C COMPRESSOR RELAY
A/C FRONT COMPRESSOR WASHER PUMP RELAY RELAY
ADDITIONAL INSTRUMENT
ALTERNATOR
AMPLIFIER
AMPLIFIER (IF EQUIPPED)
BATTERY
BLK/GRN WIRE
BLK/GRY/YEL WIRE
BRN WIRE
CAR ACCESS SYSTEM
CONVERTIBLE EXCEPT CONVERTIBLE
CONVERTIBLE EXCEPT CONVERTIBLE CONVERTIBLE, COUPE, ROADSTER
DME CONTROL MODULE
DRIVER'S SEAT HEATING MODULE
DRIVER'S SEAT HEATING MODULE TRAILER ROLLOVER MODULE PROTECTION CONTROLLER
DYNAMIC STABILITY CONTROL (DSC)
ELECTRO- CHROMIC INTERIOR REAR-VIEW MIRROR
ELECTRO- MECHANICAL POWER STEERING
EXCEPT CONVERTIBLE
EXCEPT CONVERTIBLE CONVERTIBLE
FOOTWELL MODULE
FRONT WASHER PUMP RELAY
FUEL INJECTORS RELAY
FUEL PUMP RELAY
FUEL VALVE- INJECTORS TRONIC RELAY RELAY
FUSE
FUSE 10
FUSE BOX
FUSE BOX (RIGHT REAR FUSE OF ENGINE COMPT)
FUSE FUSE
FUSE FUSE 10
FUSE FUSE FUSE FUSE
GRN/RED WIRE
GRY WIRE
HEADLIGHT CLEANING SYSTEM RELAY
HEATER BLOWER RELAY
HORN HEATER RELAY BLOWER RELAY
HORN RELAY
INTELLIGENT BATTERY SENSOR
INTELLIGENT BATTERY SENSOR (ON BATTERY)
JUNCTION BOX (RIGHT KICK PANEL)
NCA WIRE
OBDII SOCKET
ON BATTERY)
PASSENGER'S SEAT HEATING MODULE
REAR DRIVER'S SIDE POWER WINDOW RELAY
REAR DRIVER'S SIDE POWER WINDOW RELAY (COUNTRYMAN)
REAR WASHER PUMP RELAY
REAR WINDOW HEATED RELAY
REAR WINDOW WIPER RELAY
REAR WINDOW WIPER RELAY (EXCEPT CONVERTIBLE)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BLU/YEL WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
ROLLOVER PROTECTION CONTROLLER
SELECTOR LEVER POSITION SWITCH
SIREN W/ TILT ALARM SENSOR
START STOP UNIT
STARTER
STEERING COLUMN SWITCH CLUSTER
TELEPHONE RETROFIT PACKAGES CONNECTOR
TO ELECTRONICS JUNCTION BOX (DIAGRAM 3 OF 3)
TO FRONT POWER DISTRIBUTION BOX (DIAGRAM 2 OF 3)
TRAILER MODULE
TRANSMISSION CONTROL
TRANSMISSION CONTROL MODULE (A/T)
USB HUB (W/O TELEPHONE FOOTWELL CAR FUNCTION) MODULE ACCESS SYSTEM
USB- HUB
VALVE- TRONIC RELAY
W/ HIFI AMPLIFIER
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 3) -> HEADLIGHT CLEANING SYSTEM RELAY
