MINI Cooper II facelift (2010-2015) crankcase ventilation bypass Wiring diagram
This page shows the only wiring diagram for the component.crankcase ventilation bypass, which is found in the car MINI Cooper II facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crankcase ventilation bypass (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/VIO WIRE
CRANKCASE VENTILATION BYPASS
DME CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
FUEL INJECTION 1
FUEL INJECTION 2
FUEL INJECTION 3 (TOP RIGHT SIDE OF ENGINE)
FUEL INJECTION 4
GND ACTUATOR
GND FRICTION
GND PUMP
GND SENS
GRN WIRE
GRY WIRE
IGN COIL 1 SIG
IGN COIL 2 SIG
IGN COIL 3 SIG
IGN COIL 4 SIG
INJ 1 SIG
INJ 2 SIG
INJ 3 SIG
INJ 4 SIG
NCA WIRE
ORG/ WIRE
PVC HEATER
RED/GRN WIRE
SIG METER
SIG MOTOR
SIG OIL PRESS
SIG SENS
SIG VLV
SPLY MOTOR
SPLY SENS
TERM 15 SPLY
VIO WIRE
VLV ACTI
VLVETRONIC GND
VLVETRONIC SIG
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo (3 of 4) -> CRANKCASE VENTILATION BYPASS
