Wiring diagram engine performance 1.6l turbo, convertible for MINI Cooper II (2006-2010)

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CRUISE CONTROL SYSTEM DIGITAL MOTOR ELECTRONICS CONTROL UNIT (LEFT SIDE OF ENGINE COMPT) ELECTRIC FUEL PUMP ELECTRIC THROTTLE ACTUATOR FUEL PUMP RELAY FUSE FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM) GRN/BLU WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR (BEFORE CATALYTIC CONVERTER) (FRONT EXHAUST PIPE) HOT AT ALL TIMES HOT IN ON OR START INTAKE AIR PRESSURE SENSOR (BEFORE COMPRESSOR) INTAKE AIR TEMPERATURE/ PRESSURE SENSOR 1 (LEFT SIDE OF ENGINE) NCA WIRE ORG/ WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE STARTING/ CHARGING SYSTEM TRANSMISSION SYSTEM WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

3 (LEFT SIDE OF ENGINE COMPT) BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLU/RED WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR (RIGHT FRONT SIDE OF ENGINE) CRANKSHAFT POSITION SENSOR (BOTTOM OF ENGINE) CYL 1 CYL 2 CYL 3 CYL 4 DME RELAY FUEL INJECTORS FUEL TANK VENT VALVE SOLENOID VALVE (LEFT SIDE OF ENGINE) FUSE FUSE HOLDER GRN/BLU WIRE GRN/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES LEAKAGE DIAGNOSIS PUMP (RIGHT REAR WHEELWELL) NCA WIRE ORG/ WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE

ACCELERATOR PEDAL POSITION SENSOR (RIGHT SIDE OF LEFT FOOTWELL) AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (LEFT SIDE OF LEFT FOOTWELL) BRN WIRE BRN/BLK WIRE BRN/BLK/YEL WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS CONTROL UNIT (LEFT SIDE OF ENGINE COMPT) FUSE FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM) FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT) GRN/BLU WIRE GRN/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEATED OXYGEN SENSOR (AFTER CATALYTIC CONVERTER) (FRONT EXHAUST PIPE) HOT AT ALL TIMES HOT IN ACC, RUN OR START NCA WIRE ORG/ WIRE RED/GRN WIRE RED/WHT WIRE SHIFT INTERLOCK SYSTEM STARTING/ CHARGING SYSTEM TRANSMISSIONS SYSTEM VIO/BLK/YEL WIRE VIO/GRY WIRE VIO/WHT WIRE VOLUTE SPRING WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
