MINI Cooper II (2006-2010) Cooling fan circuit, convertible with single stage cooling fans

BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS CONTROL UNIT (LEFT SIDE OF ENGINE COMPT) ELECTRIC FAN 1 MOTOR ELECTRIC FAN RELAY ENGINE COOLANT TEMPERATURE (ECT) SENSOR (REAR OF ENGINE) FUSE FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT) GRN WIRE HOT AT ALL TIMES HOT W/ DME RELAY ENERGIZED RED WIRE RED/BLU WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
