MINI Cooper II (2006-2010) windscreen wiper switch wiring diagram
This page shows the only wiring diagram for the component.windscreen wiper switch, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
windscreen wiper switch wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/BLU/YEL WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/WHT/YEL WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FAST/ SLOW WIPER MOTOR RELAY
FRONT WASHER PUMP RELAY
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT)
GENERAL MODULE CONTROL UNIT (BEHIND RIGHT FOOTWELL)
GRN WIRE
GRY/BLK/YEL WIRE
HOT AT ALL TIMES
HOT IN ACC, ON OR START
HOT IN ON OR START
INSTRUMENT CLUSTER CONTROL MODULE
ON/OFF WIPER MOTOR RELAY
RAIN SENSOR (WINDSHIELD TOP)
RED WIRE
RED/BLK/YEL WIRE
VIO WIRE
VIO/WHT WIRE
WASHER FLUID LEVEL SWITCH
WASHER PUMP
WHT WIRE
WHT/RED/YEL WIRE
WINDSCREEN WIPER SWITCH
WIPER MOTOR
YEL WIRE
Go to component -> Front wiper/washer circuit, convertible -> WINDSCREEN WIPER SWITCH
