MINI Cooper II (2006-2010) turn indicator/ low beam switch Wiring diagram
This page shows the only wiring diagram for the component.turn indicator/ low beam switch, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn indicator/ low beam switch (1 of 1)
A/T
AUTOMATIC A/C
AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
BLOWER MOTOR
BLOWER OUTPUT STAGE
BRN WIRE
BRN/BLK WIRE
CONVERTIBLE SOFT TOP CONTROL MODULE
DIGITAL CLOCK
DRIVER'S DOOR ENTRANCE LIGHT
DRIVER'S DOOR SYSTEM LOCK
DRIVER'S PASSENGER'S SIDE SIDE FOOTWELL FOOTWELL LIGHT LIGHT
DRIVER'S SIDE MAKE-UP MIRROR LIGHT
EGS TRANSMISSION
ELECTRO- CHROMIC STEERING INTERIOR ANGLE REAR-VIEW SENSOR MIRROR
ELECTRONIC IMMOBILIZER CONTROL UNIT
FRESH AIR/AIR RECIR- CULATION FLAP MOTOR
HEATING, A/C CONTROL MODULE
HEATING/ AIR CON- DITIONING CONTROL PANEL SWITCH PANEL
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR PROTECTION I CONTROL MODULE
INTERIOR TEMPER- ATURE/ FAN SENSOR
LEFT FRONT DOOR OPENER LIGHTING DRIVER'S SIDE OUTSIDE MIRROR
LEFT STORAGE GLOVE COMPARTMENT BOX LOCK LIGHT MICROSWITCH
MANUAL A/C
MIRROR ADJUSTMENT SWITCH
NCA WIRE
OBDII CONNECTOR
ON-BOARD MONITOR BRAKE CLUTCH CONTROL LIGHT SWITCH UNIT SWITCH MODULE
OUTSIDE MIRROR FOLD-IN CONTROL UNIT
RADIO RADIO CONTROL CONTROL UNIT UNIT
REAR POWER WINDOW SWITCH
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER MOTOR RELAY
STEERING CONTROL MODULE FAN RELAY
TIRE FAILURE INDICATOR SWITCH
TIRE PRESSURE CONTROL (RDC)
TIRE PRESSURE CONTROL SWITCH
TRANSMISSION CONTROL UNIT
TURN INDICATOR/ LOW BEAM SWITCH
W/ BOOST W/ WAVE RADIO RADIO
WINDSHIELD WIPER SWITCH
Go to component -> Ground distribution circuit, convertible (3 of 4) -> TURN INDICATOR/ LOW BEAM SWITCH
