MINI Cooper II (2006-2010) selector lever postion switch Wiring diagram
This page shows the only wiring diagram for the component.selector lever postion switch, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector lever postion switch (1 of 1)
A/T
ANTI-LOCK BRAKES SYSTEM
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
CAR ACCESS SYSTEM (LEFT TOP SIDE OF DASH)
CLUTCH MODULE (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DME CONTROL MODULE
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HEATING/AIR CONDITIONING SYSYTEM
HOOD CONTACT SWITCH (LEFT REAR SIDE OF ENGINE COMPT)
M/T
MIRRORS SYSTEM
ORG/GRN WIRE
PASSENGER'S SEAT OCCUPANCY DETECTION
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
ROOF OPERATING UNIT
SELECTOR LEVER POSTION SWITCH
START STOP UNIT
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM POWER DISTRIBUTION SYSTEM
TRANSMISSION CONTROL
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit, except convertible (1 of 2) -> SELECTOR LEVER POSTION SWITCH
