MINI Cooper II (2006-2010) roof operating unit passenger air bag deactivation indicator lamp Wiring diagram

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE CAN-BUS HIGH CAN-BUS LOW CAR ACCESS SYSTEM COMPUTER DATA LINES DRIVER'S AIR BAG INFLATOR ASSEMBLIES DRIVER'S SEAT BELT BUCKLE CONTACT DRIVER'S SIDE B-PILLAR AIR BAG SENSOR FRONT DRIVER'S SIDE DOOR AIR BAG SENSOR FUSE GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES JUNCTION BOX MULTIPLE RESTRAINT SYSTEM CONTROL MODULE NCA WIRE ORG/GRN WIRE PASSENGER AIR BAG DEACTIVATION SWITCH PASSENGER'S AIR BAG INFLATOR ASSEMBLIES PASSENGER'S SEAT BELT BUCKLE CONTACT PASSENGER'S SEAT OCCUPANCY DETECTION POS - POS + RED WIRE ROOF OPERATING UNIT PASSENGER AIR BAG DEACTIVATION INDICATOR LAMP STEERING COLUMN SWITCH CLUSTER SYSTEM VIO WIRE VIO/BLU WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE
