MINI Cooper II (2006-2010) rear power window switch front left door opener light Wiring diagram
This page shows the only wiring diagram for the component.rear power window switch front left door opener light, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear power window switch front left door opener light (1 of 1)
AUXILIARY INSTRUMENT CLUSTER
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
DRIVER'S DOOR ENTRANCE LIGHT
DRIVER'S SIDE
DRIVER'S SIDE MAKE-UP MIRROR LIGHT
FOOTWELL LIGHT
FRONT INTERIOR/ READING LAMP
FRONT RIGHT DOOR OPENER LIGHT
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GENERAL MODULE CONTROL UNIT (BEHIND RIGHT FOOTWELL)
GLOVE BOX LIGHT
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT SWITCH
INTERIOR LIGHT)
LEFT READING LIGHT
LUGGAGE COMPARTMENT LIGHT
PASSENGER'S DOOR ENTRANCE LIGHT
PASSENGER'S SIDE +
PASSENGER'S SIDE MAKE-UP MIRROR LIGHT
REAR POWER WINDOW SWITCH FRONT LEFT DOOR OPENER LIGHT
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT READING LIGHT
SWITCH PANEL
TOP LIGHT
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ FOOTWELL LIGHTS
W/ INTERIOR LIGHT PACKAGE
W/O FOOTWELL LIGHTS
W/O INTERIOR LIGHT PACKAGE
YEL WIRE
Go to component -> Courtesy lamps circuit, convertible -> REAR POWER WINDOW SWITCH FRONT LEFT DOOR OPENER LIGHT
