MINI Cooper II (2006-2010) on/off wiper motor brake relay fluid level switch Wiring diagram
This page shows the only wiring diagram for the component.on/off wiper motor brake relay fluid level switch, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on/off wiper motor brake relay fluid level switch (1 of 1)
AMPLIFIER
BLOWER SWITCHING UNIT
BRN WIRE
DIGITAL MOTOR ELECTRONICS CONTROL UNIT
ELECTRIC LEFT SIDE FAN I MARKER MOTOR LIGHT
HEADLIGHT WASHER PUMP
HYDRAULIC PUMP STEERING CONTROL UNIT
LEFT FRONT AUXILIARY LEFT FLASHER UNIT HORN
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLIGHT
LEFT PARKING LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT WINDSHIELD WASHER JET HEATER
LUGGAGE COMPARTMENT CD LIGHT CHANGER
MICROWAVE MICROWAVE SENSOR, SENSOR, DRIVER'S PASSENGER'S DOOR DOOR
MICROWAVE MICROWAVE SENSOR, SENSOR, REAR LEFT REAR RIGHT
NCA WIRE
ON/OFF WIPER MOTOR BRAKE RELAY FLUID LEVEL SWITCH
PARK DISTANCE CONTROL RIGHT UNIT (PDC) TAILLIGHT
REAR RIGHT BRAKE PAD REAR SENSOR FOG LIGHT RIGHT REAR SIDE MARKER LIGHT
RIGHT FOG LIGHT
RIGHT FRONT AUXILIARY FLASHER UNIT
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HORN
RIGHT PARKING LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT WINDSHIELD WASHER JET HEATER
SINGLE STAGE
SIREN W/ TILT ALARM SENSOR
TWO STAGE
UNDERHOOD LIGHT SWITCH
WASHER FLUID LEVEL SWITCH
WASHER PUMP
WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit, convertible (2 of 4) -> ON/OFF WIPER MOTOR BRAKE RELAY FLUID LEVEL SWITCH
