MINI Cooper II (2006-2010) (lower steering column) steering angle sensor Wiring diagrams
This page contains all the electrical diagrams for the component. (lower steering column) steering angle sensor, in which he is found in the car MINI Cooper II (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
(lower steering column) steering angle sensor wiring diagram (1 of 2)
ABS/DSC UNIT (RIGHT REAR OF ENGINE COMPT)
BLK WIRE
BLK/RED/WHT WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT/YEL WIRE
BRAKE FLUID LEVEL SWITCH (LEFT SIDE OF ENGINE COMPT)
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS CONTROL UNIT (LEFT REAR ENGINE COMPT)
DSC SENSOR (TRANSVERSE ACCELERATION SENSOR) (UNDER LEVER COVER)
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GRN WIRE
GRN/BLU/YEL WIRE
GRN/RED WIRE
GRN/RED/YEL WIRE
GRN/YEL WIRE
GRY/WHT WIRE
HOT AT ALL TIMES FUSE
HOT AT ALL TIMES FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT) FUSE
HOT IN ACCY, RUN, START FUSE
HOT IN ON OR START FUSE
INTERIOR LIGHTS
LEFT FRONT SPEED SENSOR
LEFT REAR SPEED SENSOR
NAVIGATION COMPUTER (UNDER LEFT FRONT SEAT)
NCA WIRE
OUTSIDE MIRROR FOLD IN CONTROL UNIT (LEFT SIDE OF LEFT FOOTWELL)
RED WIRE
RED/BRN WIRE
RED/GRN/YEL WIRE
RED/VIO WIRE
RIGHT FRONT SPEED SENSOR
RIGHT REAR SPEED SENSOR
SWITCH PANEL
SYSTEM
TIRE FAILURE INDICATOR (RPA) SWITCH
VIO WIRE
VIO/WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> Anti-lock brakes circuit, convertible with dynamic stability control -> (LOWER STEERING COLUMN) STEERING ANGLE SENSOR
(lower steering column) steering angle sensor wiring diagram (2 of 2)
ABS CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
ABS/DSC UNIT (RIGHT REAR OF ENGINE COMPT)
BLU WIRE
BRN WIRE
BRN/BLK WIRE
DIGITAL MOTOR ELECTRONICS CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GRN WIRE
GRN/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER MODULE
OBDII SOCKET
RED WIRE
RED/BLU/YEL WIRE
STEERING CONTROL UNIT/ HYDRAULIC PUMP (LOWER LEFT SIDE OF ENGINE)
TRANSMISSION CONTROL UNIT (COOPER S)
VIO/WHT WIRE
W/ DSC
W/O DSC
W/O DSC, W/ TRACTION CONTROL
W/O DSC, W/0 TRACTION CONTROL
WHT/RED WIRE
YEL WIRE
Go to component -> Data link connector circuit, convertible -> (LOWER STEERING COLUMN) STEERING ANGLE SENSOR
