MINI Cooper II (2006-2010) left window Wiring diagram
This page shows the only wiring diagram for the component.left window, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left window (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY/YEL WIRE
CENTRAL LOCK
DRIVER'S DOOR SYSTEM LOCK
DRIVER'S WINDOW MOTOR
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GENERAL MODULE CONTROL UNIT (BEHIND RIGHT FOOTWELL)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT REAR WINDOW REGULATOR MOTOR
LEFT WINDOW
PASSENGER'S DOOR SYSTEM LOCK
PASSENGER'S WINDOW MOTOR
REAR POWER WINDOW SWITCH
RED/BLU WIRE
RED/VIO WIRE
RIGHT REAR WINDOW REGULATOR MOTOR
RIGHT WINDOW
SWITCH PANEL
VIO WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Power windows circuit, convertible -> LEFT WINDOW
