MINI Cooper II (2006-2010) left tank half fuel level sensor wiring diagram
This page shows the only wiring diagram for the component.left tank half fuel level sensor, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left tank half fuel level sensor wiring diagram (1 of 1)
ADDITIONAL INSTRUMENT
BLK WIRE
BLK/BRN WIRE
BLK/RED/WHT WIRE
BLK/RED/YEL WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/BRN/YEL WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK/WHT WIRE
BRN/BLK/YEL WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC FUEL PUMP
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY/YEL WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
JUNCTION BOX (RIGHT SIDE OF RIGHT FOOTWELL)
LEFT FRONT BRAKE PAD WEAR SENSOR (FRONT OF LEFT FRONT WHEEL)
LEFT TANK HALF FUEL LEVEL SENSOR
NCA WIRE
ORG/GRN WIRE
OUTSIDE TEMPERATURE SENSOR
PARKING BRAKE WARNING SWITCH (CENTER CONSOLE)
RED/GRN WIRE
RED/YEL WIRE
RIGHT REAR BRAKE PAD WEAR SENSOR (BEHIND RIGHT REAR WHEEL)
RIGHT TANK HALF FUEL LEVEL SENSOR
YEL WIRE
Go to component -> Instrument cluster circuit, except convertible -> LEFT TANK HALF FUEL LEVEL SENSOR
