MINI Cooper II (2006-2010) left front direction indicator light repeater Wiring diagram
This page shows the only wiring diagram for the component.left front direction indicator light repeater, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front direction indicator light repeater (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DIRECTION INDICATOR LIGHT
FUSE
GRN WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES JUNCTION BOX (RIGHT SIDE OF RIGHT FOOTWELL)
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT FRONT DIRECTION INDICATOR LIGHT REPEATER
LEFT FRONT SIDE MARKER LIGHT
LEFT HEAD- LIGHT DIRECTION INDICATOR LIGHT
LEFT LICENCE PLATE LIGHT
ORG/GRN WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DIRECTION INDICATOR LIGHT REPEATER
RIGHT FRONT SIDE MARKER LIGHT LEFT REAR SIDE MARKER LIGHT
RIGHT HEAD- LIGHT
RIGHT LICENCE PLATE LIGHT
RIGHT REAR SIDE MARKER LIGHT
TRAILER MODULE
TRAILER SOCKET
TRUNK LID PUSH- BUTTON/ LICENSE PLATE LIGHTS
YEL WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit, except convertible (1 of 2) -> LEFT FRONT DIRECTION INDICATOR LIGHT REPEATER
