MINI Cooper II (2006-2010) ground 30 ground Wiring diagram
This page shows the only wiring diagram for the component.ground 30 ground, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground 30 ground (1 of 1)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN L
COMPUTER DATA LINES SYSTEM
ENERGIZED JUNCTION BOX (RIGHT SIDE OF RIGHT FOOTWELL) FUSE
EXCEPT CONVERTIBLE
FRONT WHEEL)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GROUND 30 GROUND
GRY WIRE
HOT AT ALL TIMES FUSE HOLDER 2 FUSE (BEHIND LEFT FOOTWELL TRIM)
HOT W/ TERMINAL
LEFT FRONT ELECTRONIC WHEEL MODULE
LEFT FRONT RDS TRANSMITTER
LEFT REAR ELECTRONIC WHEEL MODULE
LEFT REAR RDC TRANSMITTER (BEHIND LEFT REAR WHEEL)
LF TRANSMIT RF TRANSMIT RF TRANSMIT LR TRANSMIT RR TRANSMIT RR TRANSMIT
ORG/GRN WIRE
RDC ANTENNA
RDC ANTENNA (BEHIND RIGHT REAR WHEEL)
RED WIRE
RED/BLU WIRE
RIGHT FRONT ELECTRONIC WHEEL MODULE
RIGHT FRONT RDC TRANSMITTER (FRONT OF RIGHT
RIGHT REAR ELECTRONIC WHEEL MODULE
RIGHT REAR RDC TRANSMITTER (BEHIND RIGHT REAR WHEEL)
TIRE PRESSURE CONTROL (RDC)
WHT/RED/YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Warning systems circuit -> GROUND 30 GROUND
