MINI Cooper II (2006-2010) gear positon switch wiring diagram
This page shows the only wiring diagram for the component.gear positon switch, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
gear positon switch wiring diagram (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC IMMOBILIZER CONTROL UNIT (LEFT SIDE OF DASH)
FUSE
FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT)
GEAR POSITON SWITCH
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM) FUSE
HOT IN ON OR START
HOT W/ DME MAIN RELAY ENERGIZED
NAVIGATION, MIRRORS, EXTERIOR LIGHTS SYSTEMS
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
TRANSMISSION CONTROL UNIT (LEFT SIDE OF LEFT FOOTWELL)
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> 1.6l turbo, transmission circuit, convertible (1 of 2) -> GEAR POSITON SWITCH
