MINI Cooper II (2006-2010) gear position switch transmission control unit Wiring diagram
This page shows the only wiring diagram for the component.gear position switch transmission control unit, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gear position switch transmission control unit (1 of 1)
A/C COM- PRESSOR RELAY
AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAMSHAFT POSITION SENSOR
COOPER
COOPER S
CVT TRANSMISSION SWITCH CONTROL UNIT
DIGITAL MOTOR ELECTRONICS CONTROL UNIT
DME RELAY
ELECTRIC FAN RELAY
FROM
FROM DME RELAY (DIAGRAM 3 OF 5)
FUEL CRANKSHAFT INJECTOR POSITION CYLINDER SENSOR
FUEL INJECTOR CYLINDER
FUEL PUMP RELAY
FUEL TANK VENTILATION SOLENOID VALVE
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
FUSE HOLDER 3
GEAR AUTOMATIC INDICATOR TRANSMISSION CENTRAL LIGHT SHIFT UNIT
GEAR INDICATOR LIGHT
GEAR POSITION SWITCH TRANSMISSION CONTROL UNIT
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR AFTER CATALYTIC CONVERTER
HEATED OXYGEN SENSOR BEFORE CATALYTIC CONVERTER
IGNITION COIL
LEAKAGE DIAGNOSIS PUMP
NCA WIRE
RED WIRE
SHIFT LOCK RELAY
TO FUSE
TRANSMISSION RPM SENSOR
TRIM)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, convertible (3 of 5) -> GEAR POSITION SWITCH TRANSMISSION CONTROL UNIT
