MINI Cooper II (2006-2010) fbd receiver Wiring diagram
This page shows the only wiring diagram for the component.fbd receiver, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fbd receiver (1 of 1)
BLK/WHT WIRE
BRN WIRE
CAR ACCESS SYSTEM (LEFT TOP SIDE OF DASH)
COMFORT ACCESS CONTROL MODULE (BEHIND RIGHT REAR TRIM PANEL)
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
FBD RECEIVER
FUSE
FUSE (RIGHT SIDE OF RIGHT FOOTWELL)
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION BOX
RED/GRN WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Electrochromic mirror circuit, except convertible -> FBD RECEIVER
