MINI Cooper II (2006-2010) engine coolant temperature sensor (top right rear Wiring diagram
This page shows the only wiring diagram for the component.engine coolant temperature sensor (top right rear, which is found in the car MINI Cooper II (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine coolant temperature sensor (top right rear (1 of 1)
AIR DISTRIBUTION FLAP MOTOR (BEHIND CENTER OF DASH)
AIR DISTRIBUTION MICROSWITCH (BEHIND CENTER OF DASH)
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COOLANT PRESSURE SENSOR (W/O AUTOMATIC START STOP)
DME CONTROL MODULE
ELECTRIC FAN
ELECTRIC FAN RELAY
ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (TOP RIGHT REAR
FRONT POWER DISTRIBUTION BOX (LEFT SIDE OF
FUSE 05
FUSE 08
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ DME RELAY ENERGIZED
MIXER FLAP MOTOR (BEHIND CENTER OF DASH)
RED WIRE
SIDE OF ENGINE)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Automatic a/c circuit, except convertible (2 of 2) -> ENGINE COOLANT TEMPERATURE SENSOR (TOP RIGHT REAR
