MINI Cooper II (2006-2010) electrochromic interior rear view mirror Wiring diagrams

BLK/WHT WIRE BRN WIRE CAR ACCESS SYSTEM (LEFT TOP SIDE OF DASH) COMFORT ACCESS CONTROL MODULE (BEHIND RIGHT REAR TRIM PANEL) ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FBD RECEIVER FUSE FUSE (RIGHT SIDE OF RIGHT FOOTWELL) GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START JUNCTION BOX RED/GRN WIRE WHT/BRN WIRE YEL WIRE

ADDITIVE PUMP RELAY AUC SENSOR BLK/GRY/YEL WIRE BLK/RED/WHT WIRE BRN WIRE CAR ACCESS SYSTEM DC/DC CONVERTER DME CONTROL MODULE DME RELAY DSC SENSOR DYNAMIC STABILITY CONTROL (DSC) EJECT ULF ULF BOX SBX H SBX (IF (IF EQUIPPED) EQUIPPED) ELECTRIC FAN RELAY ELECTRIC FAN RELAY 2 ELECTRO- MECHANICAL POWER STEERING ELECTROCHROMIC INTERIOR REAR VIEW MIRROR FROM FUSE BOX (DIAGRAM 1 OF 3) FUSE FUSE FUSE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE MIRROR DRIVER'S ADJUSTMENT SEAT SWITCH HEATING MODULE NCA WIRE PARK DISTANCE CONTROL (PDC) PASSENGER'S SEAT HEATING MODULE POWER SAVING RELAY REAR FRONT CIGAR LIGHTER CIGAR LIGHTER RED WIRE RED/BLK WIRE RED/BLK/YEL WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE TELEPHONE RETROFIT PACKAGES CONNECTOR TO JUNCTION BOX (DIAGRAM 3 OF 3) TO TERMINAL 15 RELAY (DIAGRAM 3 OF 3) W/ TELEPHONE W/ TELEPHONE PROVISIONS WHT WIRE WHT/VIO WIRE WINDSCREEN HEATER RELAY WIPER RELAY 1 WIPER RELAY 2
