MINI Cooper II (2006-2010) direction ind light Wiring diagram

AUTOMATIC DRIVE LIGHT BACKUP LIGHTS CIRCUIT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE BACKUP BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM DIRECTION IND LIGHT FUSE FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM) GENERAL MODULE CONTROL UNIT (BEHIND RIGHT FOOTWELL) GRN WIRE GRN/BLU WIRE GRY WIRE GRY/BLK/YEL WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HIGH BEAM HEADLIGHT FLASHER LIGHT HOT AT ALL TIMES HOT AT ALL TIMES FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT) FUSE HOT IN ACC, RUN OR START HOT IN ON OR START INSTRUMENT CLUSTER MODULE LEFT FRONT AUXILIARY FLASHER LIGHT LEFT PARKING LIGHT LEFT REAR LEFT SIDE MARKER LIGHT FRONT TURN SIGNAL LIGHT LEFT SIDE MARKER LIGHT LEFT TAILLIGHT LICENSE PLATE LIGHT PARK RED WIRE RED/WHT WIRE RED/YEL WIRE SIDE LIGHT SWITCH PANEL SYSTEM TURN TURN INDICATOR/ LOW BEAM SELECTOR VIO WIRE VIO/BRN WIRE WHT WIRE WHT/RED/YEL WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE
