MINI Cooper II (2006-2010) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car MINI Cooper II (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (81 of 124)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CATCH HALL SENSOR
COMPUTER DATA LINES SYSTEM
CONVERTIBLE SOFT TOP CONTROL MODULE (LEFT REAR PASSENGER COMPT)
CONVERTIBLE TOP CLOSED HALL SENSOR
CONVERTIBLE TOP CONTROL BUTTON
CONVERTIBLE TOP FOLDED DOWN HALL SENSOR
CONVERTIBLE TOP MOTOR
CONVERTIBLE TOP RELAY 1
CONVERTIBLE TOP RELAY 2
CROSS BRACE MICROSWITCH (REAR PARCEL SHELF)
DIGITAL MOTOR ELECTRONIC CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT STORAGE COMPT LOCK MICROSWITCH (W/ STORAGE COMPARTMENT LOCK)
NCA WIRE
REAR WINDOW SHELF MICROSWITCH (REAR PARCEL SHELF)
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT STORAGE COMPT LOCK MICROSWITCH
RIGHT STORAGE COMPT LOCK MOTOR LEFT STORAGE COMPT LOCK MOTOR
SLIDING CANVAS SUNROOF CLOSED HALL SENSOR
SLIDING CANVAS SUNROOF MOTOR
SLIDING CANVAS SUNROOF OPEN HALL SENSOR
SLIDING CANVAS SUNROOF RELAY 1
SLIDING CANVAS SUNROOF RELAY 2
STORAGE COMPT LOCK RELAY
VIO WIRE
VIO/YEL WIRE
W/ STORAGE COMPARTMENT LOCK
W/O STORAGE COMPARTMENT LOCK
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED/YEL WIRE
YEL WIRE
Go to component -> Convertible top circuit -> BRN WIRE
Wiring diagram brn (82 of 124)
BLU WIRE
BLU/VIO WIRE
BRN WIRE
DRIVER'S SIDE OUTSIDE MIRROR
FOLD-IN OUTSIDE MIRROR CONTROL UNIT (LEFT SIDE OF LEFT FOOTWELL)
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
MIRROR ADJUSTMENT SWITCH
NAVIGATION SYSTEM
NCA WIRE
PASSENGER'S SIDE OUTSIDE MIRROR
RED WIRE
RED/BLU WIRE
RED/BLU/YEL WIRE
RED/GRN WIRE
RED/WHT WIRE
WHT WIRE
YEL/GRN WIRE
Go to component -> Fold-back mirrors circuit, convertible -> BRN WIRE
Wiring diagram brn (83 of 124)
BRN WIRE
DRIVER'S SIDE OUTSIDE MIRROR
DYNAMIC STABILITY CONTROL
FUSE
FUSE (RIGHT SIDE OF RIGHT FOOTWELL)
HOT IN ON OR START
HOT W/ BI-STABLE RELAY ENERGIZED
JUNCTION BOX
MIRROR ADJUSTMENT SWITCH
NCA WIRE
OUTSIDE MIRROR FOLD-IN (BEHIND LEFT REAR TRIM PANEL)
PASSENGER'S SIDE OUTSIDE MIRROR
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
YEL/GRN WIRE
Go to component -> Fold-back mirrors circuit, except convertible -> BRN WIRE
Wiring diagram brn (84 of 124)
BLU WIRE
BRN WIRE
DRIVER'S BACKREST HEATING
DRIVER'S SEAT HEATING
DRIVER'S SEAT HEATING SWITCH
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOT IN RUN OR START
IGNITION SWITCH
NCA WIRE
OFF
PASSENGER'S BACKREST HEATING
PASSENGER'S SEAT HEATING
PASSENGER'S SEAT HEATING SWITCH
RUN WIRE
VIO WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Heated seats circuit, convertible -> BRN WIRE
Wiring diagram brn (85 of 124)
BRN WIRE
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT CUSHION HEATING
DRIVER'S SEAT HEATING MODULE
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION BOX (RIGHT SIDE OF RIGHT FOOTWELL)
NCA WIRE
PASSENGER'S SEAT BACKREST HEATING
PASSENGER'S SEAT CUSHION HEATING
PASSENGER'S SEAT HEATING MODULE
YEL/RED WIRE
Go to component -> Heated seats circuit, except convertible -> BRN WIRE
Wiring diagram brn (86 of 124)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DRIVER'S SIDE OUTSIDE MIRROR
FOLD-IN OUTSIDE MIRROR CONTROL UNIT (LEFT SIDE OF LEFT FOOTWELL)
FRONT PASSENGER'S SIDE OUTSIDE MIRROR
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GRN WIRE
GRN/RED WIRE
HORIZONTAL ACTUATOR
HOT IN ON OR START
MIRROR ADJUSTMENT SWITCH
NCA WIRE
RED WIRE
VERTICAL ACTUATOR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit, convertible -> BRN WIRE
Wiring diagram brn (87 of 124)
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DEFOGGER SYSTEM
DRIVER'S SIDE OUTSIDE MIRROR
FUSE (RIGHT SIDE OF RIGHT FOOTWELL)
GRN/WHT WIRE
GRN/YEL WIRE
HORIZONTAL ACTUATOR
HOT IN ON OR START
JUNCTION BOX
MIRROR ADJUSTMENT SWITCH
NCA WIRE
OUTSIDE MIRROR FOLD-IN (BEHIND LEFT REAR TRIM PANEL)
PASSENGER'S SIDE OUTSIDE MIRROR
RED WIRE
RED/BLU WIRE
VERTICAL ACTUATOR
YEL/GRN WIRE
Go to component -> Power mirror circuit, except convertible -> BRN WIRE
Wiring diagram brn (88 of 124)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY/YEL WIRE
CENTRAL LOCK
DRIVER'S DOOR SYSTEM LOCK
DRIVER'S WINDOW MOTOR
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GENERAL MODULE CONTROL UNIT (BEHIND RIGHT FOOTWELL)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT REAR WINDOW REGULATOR MOTOR
LEFT WINDOW
PASSENGER'S DOOR SYSTEM LOCK
PASSENGER'S WINDOW MOTOR
REAR POWER WINDOW SWITCH
RED/BLU WIRE
RED/VIO WIRE
RIGHT REAR WINDOW REGULATOR MOTOR
RIGHT WINDOW
SWITCH PANEL
VIO WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Power windows circuit, convertible -> BRN WIRE
Wiring diagram brn (89 of 124)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/RED/YEL WIRE
HOT AT ALL TIMES
RED WIRE
RED/GRY WIRE
SUNROOF CONTROL SWITCH
SUNROOF MODULE CONTROL UNIT (UNDER FRONT HEADLINER)
WHT WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Sunroof circuit, convertible -> BRN WIRE
Wiring diagram brn (90 of 124)
BLK WIRE
BRN WIRE
CLOSE SLIDE/ TILT SUNROOF SWITCH
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT W/ TERMINAL
JUNCTION BOX (RIGHT SIDE OF RIGHT FOOTWELL)
OPEN SLIDE/ TILT SUNROOF SWITCH
ORG/GRN WIRE
RED WIRE
RED/GRY WIRE
ROOF OPERATING UNIT
SUNROOF MODULE CONTROL UNIT (UNDER CENTER FRONT HEADLINER)
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Sunroof circuit, except convertible -> BRN WIRE
