MINI Cooper II (2006-2010) automatic transmission central shift unit Wiring diagrams
This page contains all the electrical diagrams for the component. automatic transmission central shift unit, in which he is found in the car MINI Cooper II (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram automatic transmission central shift unit (1 of 5)
AUTOMATIC TRANSMISSION (CVT) SWITCH
AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CONTACT SPRING (VOLUTE SPRING)
DIGITAL MOTOR ELECTRONICS CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
FUSE HOLDER 3 (LEFT SIDE OF ENGINE COMPT)
GEAR INDICATOR LIGHT
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT IN ON OR START
HOT W/ DME MAIN RELAY ENERGIZED
LEFT BUTTON PAD
LEFT STEERING WHEEL UP/DOWN PUSH BUTTON
NCA WIRE
ORG/ WIRE
RED/WHT WIRE
TRANSMISSION CONTROL UNIT (LEFT SIDE OF LEFT FOOTWELL)
TRANSMISSION RPM SENSOR
TRANSMISSION VALVE UNIT
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/ORG WIRE
Go to component -> 1.6l, transmission circuit, convertible -> AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
Wiring diagram automatic transmission central shift unit (2 of 5)
AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
GEAR INDICATOR LIGHT
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT BUTTON PAD
LEFT STEERING WHEEL UP/DOWN PUSH BUTTON
NCA WIRE
RED/BLK WIRE
SHIFT LOCK SELECTOR LEVER LOCK
VOLUTE SPRING
WHT/BLU WIRE
YEL/GRY WIRE
Go to component -> 1.6l turbo, transmission circuit, convertible (2 of 2) -> AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
Wiring diagram automatic transmission central shift unit (3 of 5)
A/T
AUTOMATIC A/C
AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
BLOWER MOTOR
BLOWER OUTPUT STAGE
BRN WIRE
BRN/BLK WIRE
CONVERTIBLE SOFT TOP CONTROL MODULE
DIGITAL CLOCK
DRIVER'S DOOR ENTRANCE LIGHT
DRIVER'S DOOR SYSTEM LOCK
DRIVER'S PASSENGER'S SIDE SIDE FOOTWELL FOOTWELL LIGHT LIGHT
DRIVER'S SIDE MAKE-UP MIRROR LIGHT
EGS TRANSMISSION
ELECTRO- CHROMIC STEERING INTERIOR ANGLE REAR-VIEW SENSOR MIRROR
ELECTRONIC IMMOBILIZER CONTROL UNIT
FRESH AIR/AIR RECIR- CULATION FLAP MOTOR
HEATING, A/C CONTROL MODULE
HEATING/ AIR CON- DITIONING CONTROL PANEL SWITCH PANEL
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR PROTECTION I CONTROL MODULE
INTERIOR TEMPER- ATURE/ FAN SENSOR
LEFT FRONT DOOR OPENER LIGHTING DRIVER'S SIDE OUTSIDE MIRROR
LEFT STORAGE GLOVE COMPARTMENT BOX LOCK LIGHT MICROSWITCH
MANUAL A/C
MIRROR ADJUSTMENT SWITCH
NCA WIRE
OBDII CONNECTOR
ON-BOARD MONITOR BRAKE CLUTCH CONTROL LIGHT SWITCH UNIT SWITCH MODULE
OUTSIDE MIRROR FOLD-IN CONTROL UNIT
RADIO RADIO CONTROL CONTROL UNIT UNIT
REAR POWER WINDOW SWITCH
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER MOTOR RELAY
STEERING CONTROL MODULE FAN RELAY
TIRE FAILURE INDICATOR SWITCH
TIRE PRESSURE CONTROL (RDC)
TIRE PRESSURE CONTROL SWITCH
TRANSMISSION CONTROL UNIT
TURN INDICATOR/ LOW BEAM SWITCH
W/ BOOST W/ WAVE RADIO RADIO
WINDSHIELD WIPER SWITCH
Go to component -> Ground distribution circuit, convertible (3 of 4) -> AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
Wiring diagram automatic transmission central shift unit (4 of 5)
A/C COM- PRESSOR RELAY
AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAMSHAFT POSITION SENSOR
COOPER
COOPER S
CVT TRANSMISSION SWITCH CONTROL UNIT
DIGITAL MOTOR ELECTRONICS CONTROL UNIT
DME RELAY
ELECTRIC FAN RELAY
FROM
FROM DME RELAY (DIAGRAM 3 OF 5)
FUEL CRANKSHAFT INJECTOR POSITION CYLINDER SENSOR
FUEL INJECTOR CYLINDER
FUEL PUMP RELAY
FUEL TANK VENTILATION SOLENOID VALVE
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
FUSE HOLDER 3
GEAR AUTOMATIC INDICATOR TRANSMISSION CENTRAL LIGHT SHIFT UNIT
GEAR INDICATOR LIGHT
GEAR POSITION SWITCH TRANSMISSION CONTROL UNIT
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR AFTER CATALYTIC CONVERTER
HEATED OXYGEN SENSOR BEFORE CATALYTIC CONVERTER
IGNITION COIL
LEAKAGE DIAGNOSIS PUMP
NCA WIRE
RED WIRE
SHIFT LOCK RELAY
TO FUSE
TRANSMISSION RPM SENSOR
TRIM)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, convertible (3 of 5) -> AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
Wiring diagram automatic transmission central shift unit (5 of 5)
A/T
AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CLUTCH SWITCH MODULE
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONIC CONTROL UNIT
ELECTRONIC IMMOBILIZER CONTROL UNIT (LEFT SIDE OF DASH)
FUSE
FUSE HOLDER 2 (BEHIND LEFT FOOTWELL TRIM)
GEAR POSITION SWITCH
GENERATOR
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE HOLDER 3 FUSE (LEFT SIDE OF ENGINE COMPT)
HOT W/ DME RELAY ENERGIZED
IGNITION SWITCH
M/T
NCA WIRE
OFF
POWER DISTRIBUTION SYSTEM BATTERY
RED WIRE
RUN WIRE
STARTER
TRANSMISSION CONTROL UNIT (1.6L A/T) (LEFT SIDE OF LEFT FOOTWELL)
VIO/GRY WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Starting circuit, convertible -> AUTOMATIC TRANSMISSION CENTRAL SHIFT UNIT
