Car Wiring Diagrams for Diversity antenna circuit, coupe for MINI Cooper I (2000-2015)

AMPLIFIER ANTENNA (UNDER DRIVER'S SEAT) ANTENNA DIVERSITY (RIGHT SIDE OF REAR COMPT DOOR) BLK WIRE BRN/WHT WIRE CCC/M-ASK RTTI (W/ CCC/M-ASK) SPLITTER RADIO (W/ RADIO) ENERGIZED JUNCTION BOX (RIGHT KICK PANEL) FRONT POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE HOT AT ALL TIMES HOT W/ TERMINAL JBE HIGH W/ MSA JBE LOW (OR) HIGH NCA WIRE RED/BLU WIRE RED/YEL WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE
