1.6l turbo, cooling fan circuit for MINI Cooper I (2000-2015)

1-TIER 1.6L TURBO 1.6L 2-TIER BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/YEL WIRE CHARACTERISTIC MAP THERMOSTAT (TOP REAR CENTER OF ENGINE) COMPUTER DATA LINES SYSTEM COOLANT PRESSURE SENSOR DME CONTROL UNIT ELECTRIC FAN (LEFT FRONT OF ENGINE COMPT) ELECTRIC FAN RELAY ELECTRIC FAN RELAY 2 ENGINE CONTROLS SYSTEM ENGINE TEMPERATURE SENSOR FRONT POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ DME RELAY ENERGIZED ORG/ WIRE RED WIRE RED/BLU WIRE W/ AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
