MINI Cooper I (2000-2015) selector lever position switch (at base of Wiring diagram
This page shows the only wiring diagram for the component.selector lever position switch (at base of, which is found in the car MINI Cooper I (2000-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector lever position switch (at base of (1 of 1)
ALL-WHEEL DRIVE VEHICLE CLUTCH (COUNTRYMAN, PACEMAN) (ON REAR OF TRANSAXLE)
BLK/RED WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DYNAMIC STABILITY CONTROL (DSC) (LEFT REAR OF ENGINE COMPT)
GEAR INDICATOR LIGHTING
GEAR SELECTOR)
GRN/GRY WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/YEL WIRE
LEFT ROCKER SWITCH
NCA WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT ROCKER SWITCH
SELECTOR LEVER POSITION SWITCH (AT BASE OF
STEERING COLUMN SWITCH CLUSTER
WHT WIRE
WHT/BLU WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Transmission circuit (2 of 2) -> SELECTOR LEVER POSITION SWITCH (AT BASE OF
