MINI Cooper I (2000-2015) rtti splitter Wiring diagrams

This page contains all the electrical diagrams for the component. rtti splitter, in which he is found in the car MINI Cooper I (2000-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rtti splitter (1 of 3)

Wiring diagram rtti splitter for MINI Cooper I (2000-2015) (1 of 3)

Get access

AMPLIFIER (UNDER DRIVER'S SEAT) ANTENNA DIVERSITY (RIGHT SIDE OF REAR COMPT DOOR) BLK WIRE BRN/WHT WIRE CCC/M-ASK (W/ CCC/M-ASK) RADIO (W/ RADIO) DIGITAL TUNER (RIGHT SIDE OF REAR COMPT) FUSE HOT AT ALL TIMES FRONT POWER DISTRIBUTION FUSE BOX (LEFT SIDE OF ENGINE COMPT) HOT W/ HOT W/ BSTABLE RELAY (VARIANT- DEPENDENT) ENERGIZED JBE HIGH JBE LOW OR HIGH JBE HIGH W/ MSA JUNCTION BOX (RIGHT KICK PANEL) LEFT SIDE WINDOW ANTENNA NCA WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED ROOF ANTENNA (CENTER REAR OF ROOF) RTTI SPLITTER W/ CCC/M-ASK W/ NAVIGATION W/O NAVIGATION WHT WIRE

Go to component -> Diversity antenna circuit, clubman -> RTTI SPLITTER

Wiring diagram rtti splitter (2 of 3)

Wiring diagram rtti splitter for MINI Cooper I (2000-2015) (2 of 3)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE BRN/WHT WIRE CD CHANGER CENTRAL INFORMATION DISPLAY COMPT DOOR) ANTENNA DIVERSITY COMPUTER DATA LINES SYSTEM DIGITAL TUNER (RIGHT SIDE OF REAR COMPT) DIVERSITY ANTENNA CIRCUIT FRONT POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE GRN GRN WIRE GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY (VARIANT-DEPENDENT) ENERGIZED HOT W/ TERMINAL JBE HIGH W/ MSA JBE HIGH JBE LOW OR HIGH JUNCTION BOX (RIGHT KICK PANEL) LEFT REAR SIDE WINDOW TV ANTENNA MINI JOYSTICK MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER RIGHT REAR SIDE WINDOW TV ANTENNA RIGHT SIDE WINDOW ANTENNA AMPLIFIER RTTI SPLITTER SATELLITE RECEIVER (UNDER PASSENGER'S SEAT) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

Go to component -> Navigation circuit, without amplifier (2 of 2) -> RTTI SPLITTER
