MINI Cooper I (2000-2015) passenger's door power window switch Wiring diagram
This page shows the only wiring diagram for the component.passenger's door power window switch, which is found in the car MINI Cooper I (2000-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's door power window switch (1 of 1)
1.6L COUNTRYMAN
1.6L TURBO COUNTRYMAN
BRN WIRE
GRY/RED WIRE
INTERIOR LIGHTS
JUNCTION BOX (RIGHT KICK PANEL)
JUNCTION BOX ELECTRONICS
PACEMAN
PASSENGER'S DOOR POWER WINDOW SWITCH
REAR DRIVER'S SIDE POWER WINDOW SWITCH
REAR PASSENGER'S SIDE POWER WINDOW SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
SYSTEM
W/ HIGH EQUIPMENT VARIANT
W/ LOW EQUIPMENT VARIANT
Go to component -> Power windows circuit, countryman & paceman (2 of 2) -> PASSENGER'S DOOR POWER WINDOW SWITCH
