MINI Cooper I (2000-2015) motor fold-in Wiring diagram
This page shows the only wiring diagram for the component.motor fold-in, which is found in the car MINI Cooper I (2000-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram motor fold-in (1 of 1)
BLK WIRE
BRN WIRE
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SIDE OUTSIDE MIRROR
ELECTRONICS JUNCTION BOX
FOLD-IN MOTOR
FOOTWELL MODULE (LEFT SIDE OF LEFT FOOTWELL)
FUSE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEATING
HORIZONTAL
HOT W/
MOTOR FOLD-IN
NCA WIRE
PASSENGER'S SIDE OUTSIDE MIRROR
RED WIRE
RELAY ENERGIZED
VERTICAL
VIO WIRE
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power mirrors circuit, with lin bus function -> MOTOR FOLD-IN
