MINI Cooper I (2000-2015) interference suppression capacitor (top right side of engine) wiring diagram
This page shows the only wiring diagram for the component.interference suppression capacitor (top right side of engine), which is found in the car MINI Cooper I (2000-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
interference suppression capacitor (top right side of engine) wiring diagram (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH (LEFT SIDE OF LEFT FOOTWELL)
BRN WIRE
BRN/BLU WIRE
COOLING FANS SYSTEM
CRANKCASE VENTILATION HEATING RELAY
DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT)
DME RELAY
ENGINE BREATHER
FRONT POWER
FUEL TANK LEAKAGE DIAGNOSTIC MODULE (FRONT OF RIGHT REAR WHEEL)
FUSE
FUSE FUSE
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HEATER 1 (RIGHT REAR SIDE OF ENGINE)
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BOX (RIGHT REAR OF ENGINE COMPT)
IGNITION COIL 2
IGNITION COIL 4
IGNITION IGNITION COIL 3 COIL 1
INTERFERENCE SUPPRESSION CAPACITOR (TOP RIGHT SIDE OF ENGINE)
ORG/ WIRE
RED WIRE
RED/VIO WIRE
RED/WHT WIRE
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l (2 of 4) -> INTERFERENCE SUPPRESSION CAPACITOR (TOP RIGHT SIDE OF ENGINE)
