MINI Cooper I (2000-2015) fuse box Wiring diagram
This page shows the only wiring diagram for the component.fuse box, which is found in the car MINI Cooper I (2000-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse box (1 of 1)
BRN WIRE
DRIVER'S SIDE HEATED WASHER NOZZLE
DRIVER'S SIDE OUTSIDE MIRROR
ELECTRONICS JUNCTION BOX
FUSE (RIGHT REAR OF ENGINE COMPT)
FUSE BOX
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
JUNCTION BOX (RIGHT KICK PANEL)
NCA WIRE
PASSENGER'S SIDE HEATED WASHER NOZZLE
PASSENGER'S SIDE OUTSIDE MIRROR
RED WIRE
WHT WIRE
YEL GRN/ WIRE
YEL WIRE
Go to component -> Washer jet heater circuit -> FUSE BOX
