MINI Cooper I (2000-2015) fuel fuel injection 3 injection 2 Wiring diagram
This page shows the only wiring diagram for the component.fuel fuel injection 3 injection 2, which is found in the car MINI Cooper I (2000-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel fuel injection 3 injection 2 (1 of 1)
BLK WIRE
BLU WIRE
CHARACTERISTIC MAP THERMOSTAT (RIGHT REAR SIDE OF ENGINE)
DME CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
ENG TEMP SENS OXYGEN SENS SIG
ENG TEMP SIG KNOCK SENS KNOCK SENS
EXHAUST VANOS SOLENOID VALVE (TOP RIGHT FRONT SIDE OF ENGINE)
FUEL FUEL INJECTION 3 INJECTION 2
FUEL INJECTION 1
FUEL INJECTION 4
FUEL TANK VENT VALVE (TOP LEFT OF ENGINE)
FUIL INJ FUIL INJ MAP THERMOSTAT ENG OIL PR SENS ENG OIL PR SENS
GRN WIRE
GRY WIRE
HOT-FILM AIR MASS METER (TOP REAR CENTER OF ENGINE)
INT TEMP SENS
INTAKE TEMPERATURE DIFFERENTIAL PRESSURE SENSOR (RIGHT REAR SIDE OF ENGINE)
INTAKE VANOS SOLENOID VALVE (RIGHT FRONT SIDE OF ENGINE)
NCA WIRE
OIL PRESSURE CONTROL VALVE (FRONT RIGHT SIDE OF ENGINE)
ORG/ WIRE
PR SENS WHEEL DRIVE FUIL INJ
TERM 15 TERM 15 CRNKSHAFT SENS SPLY TERM 15 TERM 87
TERM 87 ACT SENS HEATER ENG OIL PR SENS
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Wiring diagram engine performance 1.6l (4 of 4) -> FUEL FUEL INJECTION 3 INJECTION 2
