MINI Cooper I (2000-2015) dme control unit (left side of Wiring diagrams
This page contains all the electrical diagrams for the component. dme control unit (left side of, in which he is found in the car MINI Cooper I (2000-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dme control unit (left side of (1 of 2)
1-TIER
1.6L 1.6L TURBO
1.6L TURBO 1.6L
2-TIER
AIR DISTRIBUTION FLAP MOTOR (BEHIND CENTER OF DASH)
AIR DISTRIBUTION MICROSWITCH (BEHIND CENTER OF DASH)
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COOLANT PRESSURE SENSOR
DME CONTROL UNIT (LEFT SIDE OF
ELECTRIC FAN (LEFT FRONT OF ENGINE COMPT)
ELECTRIC FAN RELAY
ELECTRIC FAN RELAY 2 (1.6L TURBO)
ENGINE COMPT)
ENGINE CONTROLS SYSTEM
ENGINE TEMPERATURE SENSOR
FRONT POWER DISTRIBUTION BOX (LEFT SIDE OF
FUSE
GRN WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ DME RELAY ENERGIZED
MIXER FLAP MOTOR (BEHIND CENTER OF DASH)
ORG/ WIRE
RED WIRE
RED/BLU WIRE
W/ AUTOMATIC ENGINE START/STOP FUNCTION
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> DME CONTROL UNIT (LEFT SIDE OF
Wiring diagram dme control unit (left side of (2 of 2)
1-TIER
1.6L TURBO 1.6L
2-TIER
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLOWER BALLAST RESISTOR
BLOWER MOTOR (BEHIND CENTER OF DASH)
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COOLANT ENGINE TEMPERATURE PRESSURE SENSOR SENSOR
DME CONTROL UNIT (LEFT SIDE OF
ELECTRIC FAN (LEFT FRONT OF ENGINE COMPT)
ELECTRIC FAN RELAY
ELECTRIC FAN RELAY 2 (1.6L TURBO)
ENGINE COMPT)
ENGINE CONTROLS SYSTEM
FRONT POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT)
FUSE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ DME RELAY ENERGIZED
ORG/ WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
W/ AUTOMATIC ENGINE START-STOP FUNCTION
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Manual a/c circuit (2 of 2) -> DME CONTROL UNIT (LEFT SIDE OF
