Convertible top circuit for MINI Cooper SE III facelift (2018-2021)
Convertible top circuit (1 of 2)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP COMPARTMENT FLOOR MICROSWITCH
CONVERTIBLE TOP DRIVE
CONVERTIBLE TOP MODULE
FRONT INTERIOR LIGHT
FRONT POWER DISTRIBUTION BOX
FUSE 93
FUSE 94
FUSE 96
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/YEL WIRE
INCREMENTAL TRANSDUCER HALL EFFECT SENSOR
LEFT CONVERTIBLE TOP DRIVE UNIT
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
STOWAGE LOCK CLOSED HALL EFFECT SENSOR
YEL WIRE
YEL/RED WIRE
Convertible top circuit (2 of 2)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
CONVERTIBLE TOP DRIVE
CONVERTIBLE TOP MODULE
COWL PANEL LOCK DRIVE OPEN HALL EFFECT SENSOR
DIRECTION INCREMENTAL ENCODER HALL EFFECT SENSOR
FOLDING SUNROOF POSITION HALL EFFECT SENSOR
FOLDING SUNROOF, CONVERTIBLE TOP LOCKING DRIVE
FOLDING SUNROOF, SOFT TOP LOCKING DRIVE UNIT
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
INCREMENTAL TRANSDUCER HALL EFFECT SENSOR
LEFT CONVERTIBLE TOP RAISED HALL EFFECT SENSOR
NCA WIRE
POSITION INCREMENTAL ENCODER HALL EFFECT SENSOR
RED WIRE
RIGHT CONVERTIBLE TOP DRIVE UNIT
RIGHT CONVERTIBLE TOP RAISED HALL EFFECT SENSOR
SOFT TOP STOWED HALL EFFECT SENSOR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
