Radio circuit, w/ base radio & active sound design for MINI Cooper SE Countryman II (2016-2020)

AM/ FM AERIAL BLK/VIO WIRE BLUETOOTH AERIAL BODY DOMAIN CONTROLLER BRN WIRE BRN/BLU WIRE BRN/ORG (OR BRN) WIRE BRN/ORG WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DABL AERIAL FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 79 GPS AERIAL GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ HOT W/ TERMINAL NAVIGATION NCA WIRE REAR VIEW CAMERA RED/BRN WIRE RED/YEL WIRE SDARS AERIAL SELECTOR SWITCH TELEPHONE AERIAL USB/ETHERNET VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/O ALARM SYSTEM LED WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIRELESS CHARGING SHELF ANTENNA AMPLIFIER WIRELESS CHARGING STORAGE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BASIC VERSION BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/RED WIRE CENTRAL INFORMATION DISPLAY CENTRAL INSTRUMENT GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HIGH VERSION MICROPHONE MICROPHONE 2 (W/ VOICE INPUT) (RIGHT FRONT OF HEADLINER) NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO WIRE TELEMATIC COMMUNICATION BOX (RIGHT SIDE OF DASH) VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ NAVIGATION W/ TELEMATICS W/O NAVIGATION W/O TELEMATICS WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

ACTIVE SOUND DESIGN (BEHIND LEFT REAR TRIM PANEL) BASE PLATE FAN BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) FRONT POWER DISTRIBUTION BOX FUSE 101 FUSE 51 FUSE 68 FUSE 80 FUSE 91 GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ LEFT REAR MID-RANGE SPEAKER NCA WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT WOOFER RIGHT REAR MID-RANGE SPEAKER VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ WIRELESS CHARGING STORAGE W/O WIRELESS CHARGING STORAGE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE

AERIAL AMPLIFIER AERIAL AMPLIFIER (LEFT "C" PILLAR) AERIAL AMPLIFIER 2 AERIAL DIVERSITY (W/ ALARM SYSTEM LED) (CENTER REAR OF ROOF) BASE PLATE (IN CENTER CONSOLE) BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BRN (OR BRN/ORG) WIRE BRN WIRE CAR SHARING MODULE CENTER CONSOLE CLUBMAN, CONVERTIBLE COMPUTER DATA LINES SYSTEM DVD CHANGER FRONT POWER DISTRIBUTION BOX FUSE 87 GRN WIRE GRY/RED WIRE HEAD UNIT (CENTER OF DASH) HEAD UNIT BASIS W/ HOT W/ TERMINAL ID READER INSTRUMENT PANEL LEFT "C" PILLAR) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT WOOFER LEFT SIDE WINDOW AERIAL NAVIGATION NCA WIRE ORG/ WIRE REAR BUMPER AERIAL REAR BUMPER AERIAL 2 REAR SPOILER AERIAL REAR-WINDOW AERIAL RED WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT SIDE WINDOW AERIAL SELECTOR SWITCH USB CONNECTION USB/ETHERNET VIO WIRE WHT/GRN WIRE WHT/RED WIRE WLAN AERIAL YEL WIRE YEL/BRN WIRE YEL/RED WIRE
