Transmission circuit, hatchback for MINI Cooper S III (2013-2018)

BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC TRANSMISSION CONTROL FRONT POWER DISTRIBUTION BOX FUSE 81 FUSE 82 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY/RED WIRE HOT W/ HYDRAULIC CONTROL UNIT NCA WIRE OIL PRESSURE SWITCH OIL PUMP CONTROLLED SOLENOID PRESSURE CONTROL VALVE RED WIRE RELAY 1 ENERGIZED RPM SENSOR SELECTOR ANGLE SENSOR SOLENOID VALVE 1 SOLENOID VALVE 2 SOLENOID VALVE 3, SOLENOID VALVE 5 TEMPERATURE SENSOR 1 TEMPERATURE SENSOR 2 TOP OF TRANSMISSION) WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE

BLK WIRE BLU WIRE BODY DOMAIN CONTROLLER (RIGHT KICK PANEL) BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE GEAR INDICATOR LIGHT GRN WIRE GRN/BLU WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HORNS SYSTEM LEFT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK LEFT SHIFT PADDLE NCA WIRE RED/WHT WIRE RED/YEL WIRE RIGHT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK RIGHT SHIFT PADDLE SELECTOR LEVER (AT BASE OF GEAR SELECTOR) STEERING COLUMN SWITCH CLUSTER WHT/BLU WIRE YEL WIRE YEL/BLU WIRE
