MINI Cooper S III (2013-2018) Parking assistant circuit, hatchback

BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/VIO WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT POWER DISTRIBUTION BOX FUSE 55 GRN/BLK WIRE GRN/WHT WIRE HOT W/ LEFT FRONT CENTER ULTRASONIC SENSOR LEFT FRONT OUTER ULTRASONIC SENSOR LEFT PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR LEFT REAR CENTER ULTRASONIC SENSOR LEFT REAR OUTER ULTRASONIC SENSOR PARKING MANEUVERING ASSISTANT RED WIRE RELAY ENERGIZED RIGHT FRONT CENTER ULTRASONIC SENSOR RIGHT FRONT OUTER ULTRASONIC SENSOR RIGHT PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR RIGHT REAR CENTER ULTRASONIC SENSOR RIGHT REAR OUTER ULTRASONIC SENSOR YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/WHT WIRE
