Navigation circuit, hatchback w/ hifi radio w/o active sound design for MINI Cooper S III (2013-2018)

BLK WIRE BLU WIRE BLUETOOTH ANTENNA BODY DOMAIN CONTROLLER BRN WIRE BRN/BLU WIRE BRN/RED WIRE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 79 FUSE 87 GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT HEAD UNIT BASIS HOT W/ TERMINAL MICROPHONE MICROPHONE 2 (RIGHT FRONT OF ROOF) NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE REVERSING CAMERA ROOF ANTENNA USB/ETHERNET VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ NAVIGATION W/ OPTIONAL EQUIPMENT W/O OPTIONAL EQUIPMENT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTER FRONT MID-RANGE SPEAKER CENTER FRONT TWEETER CENTRAL INFORMATION DISPLAY CENTRAL INSTRUMENT DVD CHANGER GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/RED WIRE HEAD UNIT LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT WOOFER VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BASE PLATE FAN BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM CONTROLLER FRONT POWER DISTRIBUTION BOX FUSE 101 FUSE 129 FUSE 51 FUSE 68 FUSE 80 GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HIFI AMPLIFIER (BEHIND LEFT REAR TRIM PANEL) HOT AT ALL TIMES HOT W/ LEFT FRONT TWEETER LEFT FRONT WOOFER NCA WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY 1 ENERGIZED RELAY 2 ENERGIZED RELAY ENERGIZED RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER TOUCHBOX VIO WIRE VIO/BRN WIRE VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

ANTENNA DIVERSITY AUX-IN CONNECTION BASE PLATE BLK WIRE BLU WIRE BRN WIRE CAR SHARING MODULE CHANGEOVER SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE HEAD UNIT HEAD UNIT BASIS ID READER MOST DATA BUS CIRCUIT NCA WIRE ORG/ WIRE RED WIRE RED/BRN WIRE RED/YEL WIRE ROOF ANTENNA TELEMATICS COMMUNICATION BOX USB CONNECTION USB/ETHERNET VIO WIRE W/ NAVIGATION W/ OPTIONAL EQUIPMENT W/O OPTIONAL EQUIPMENT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
