Car Wiring Diagrams for Contact-free tailgate opening circuit for MINI Cooper S Countryman III (2023-2024)
Contact-free tailgate opening circuit
BLK WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BUMPER ANTENNA
COMPUTER DATA LINES SYSTEM
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
CONTACT-FREE TAILGATE OPENING LOWER SENSOR
CONTACT-FREE TAILGATE OPENING UPPER SENSOR
COOPER COUNTRYMAN
FUSE 12
GRY/BLK WIRE
GRY/RED WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
RED/VIO WIRE
WHT/BLU WIRE
