MINI Cooper S Countryman III (2023-2024) tail light/brake Wiring diagram
This page shows the only wiring diagram for the component.tail light/brake, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail light/brake (1 of 1)
AUXILIARY STOP LAMP
BLK WIRE
BLK/WHT WIRE
BLK/WHT) GRY/BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BRN (OR NCA) WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER ASSISTANCE SYSTEM OPERATING UNIT W/ HAZARD WARNING SWITCH
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
INDICATOR
INTERFERENCE SUPPRESSOR FILTER
LEFT BOTTOM REAR LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT LICENSE PLATE LAMP
LEFT REAR SIDE MARKER LIGHT
LIGHT
NCA WIRE
ORG/ WIRE
RIGHT BOTTOM REAR LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT LICENSE PLATE LAMP
RIGHT REAR SIDE MARKER LIGHT
TAIL LIGHT/BRAKE
TRAILER TOW CIRCUIT
TURN
VIO/GRY WIRE
VIO/YEL WIRE
W/ INTERFERENCE SUPPRESSION FILTER
W/ LED
W/O INTERFERENCE SUPPRESSION FILTER
W/O LED
Go to component: -> Exterior lamps circuit (2 of 3) -> TAIL LIGHT/BRAKE
