MINI Cooper S Countryman III (2023-2024) rear driver's side door pocket lighting Wiring diagram
This page shows the only wiring diagram for the component.rear driver's side door pocket lighting, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear driver's side door pocket lighting (1 of 1)
BRN WIRE
BRN/ORG WIRE
BRN/YEL WIRE
CENTRAL INSTRUMENT
COUNTRYMAN CLUBMAN
DASHBOARD LIGHTING CENTER
DOOR LOCKS SYSTEM
DRIVER'S DOOR CENTRAL LOCKING BUTTON
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S DOOR POCKET LIGHTING 2
DYNAMIC STABILITY CONTROL (DSC)
FRONT PASSENGER DOOR CENTRAL LOCKING BUTTON
FRONT PASSENGER DOOR POCKET LIGHTING
FRONT PASSENGER DOOR POCKET LIGHTING 2
FRONT PASSENGER DOOR POWER WINDOW SWITCH
GRY/RED WIRE
HEAD UNIT (CENTER OF DASH)
PARKING BRAKE BUTTON (CLUBMAN)
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
REAR DRIVER'S SIDE DOOR POCKET LIGHTING
REAR DRIVER'S SIDE POWER WINDOW SWITCH
REAR PASSENGER'S SIDE DOOR POCKET LIGHTING
REFUELING BUTTON
USB CHARGING PORT 4
USB CHARGING SOCKET 3
VEHICLE INTERIOR TAILGATE BUTTON
Go to component: -> Instrument illumination circuit (2 of 2) -> REAR DRIVER'S SIDE DOOR POCKET LIGHTING
