MINI Cooper S Countryman III (2023-2024) power distribution, anti-theft systems Wiring diagram
This page shows the only wiring diagram for the component.power distribution, anti-theft systems, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power distribution, anti-theft systems (1 of 1)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/BRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
INSTRUMENT CLUSTER SYSTEM
ORG/ WIRE
POWER DISTRIBUTION, ANTI-THEFT SYSTEMS
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
TRANSMISSIONS SYSTEM
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/BLU WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component: -> Body control modules circuit (3 of 4) -> POWER DISTRIBUTION, ANTI-THEFT SYSTEMS
