MINI Cooper S Countryman III (2023-2024) optional equipment system Wiring diagram
This page shows the only wiring diagram for the component.optional equipment system, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram optional equipment system (1 of 1)
BLU WIRE
BLU/RED WIRE
BRN WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
CHRONO METER
ELECTRICAL MACHINE ELECTRONICS
ELECTROCHROMIC INTERIOR MIRROR
FRONT INTERIOR LIGHT
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
HYBRID PRESSURE REFUELLING ELECTRONIC CONTROL UNIT
LEFT HEADLIGHT
LONGITUDINAL TORQUE DISTRIBUTION
NCA WIRE
OPTIONAL EQUIPMENT SYSTEM
PNK WIRE
PNK/BLK WIRE
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
REAR VIEW CAMERA
RED WIRE
RED/BLU WIRE
RIGHT HEADLIGHT
VEHICLE SOUND GENERATOR
VIO WIRE
VIO/BLU WIRE
VIO/YEL WIRE
W/ LED
W/ TERMINATING RESISTOR
W/O TERMINATING RESISTOR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component: -> High/low bus circuit (3 of 4) -> OPTIONAL EQUIPMENT SYSTEM
