MINI Cooper S Countryman III (2023-2024) left side reading light Wiring diagram
This page shows the only wiring diagram for the component.left side reading light, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side reading light (1 of 1)
AMBIENT LIGHT
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FRONT INTERIOR LIGHT
FRONT POWER DISTRIBUTION BOX
FUSE 32
FUSE 62
FUSE 70
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHTING
INTERIOR LIGHTS BUTTON
INTERIOR LIGHTS LOCATOR LIGHTING BUTTON
LEFT FRONT VANITY MIRROR LIGHT
LEFT READING LAMP BUTTON
LEFT READING LIGHT BUTTON
LEFT SIDE READING LIGHT
ORG/ WIRE
REAR INTERIOR LIGHT
REAR INTERIOR LIGHTING
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT READING LAMP BUTTON
RIGHT READING LIGHT
RIGHT READING LIGHT BUTTON
VIO WIRE
VIO/YEL WIRE
W/ PANORAMIC ROOF
W/O PANORAMIC ROOF
YEL/BLU WIRE
Go to component: -> Courtesy lamps circuit (1 of 4) -> LEFT SIDE READING LIGHT
