MINI Cooper S Countryman III (2023-2024) front passenger's seat cushion heating Wiring diagram

This page shows the only wiring diagram for the component.front passenger's seat cushion heating, which is found in the car MINI Cooper S Countryman III (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger's seat cushion heating (1 of 1)

Wiring diagram front passenger's seat cushion heating for MINI Cooper S Countryman III (2023-2024)

Get access

AIR CONDITIONING BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER THIGH SUPPORT HEATING DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT HEATING ELECTRONICS DRIVER'S SEAT SURFACE HEATING FRONT PASSENGER SEAT HEATING ELECTRONICS FRONT PASSENGER THIGH SUPPORT HEATING FRONT PASSENGER'S SEAT BACKREST HEATING FRONT PASSENGER'S SEAT CUSHION HEATING FRONT POWER DISTRIBUTION BOX FUSE 127 FUSE 128 HOT W/ NCA WIRE RED/GRN WIRE RELAY 2 ENERGIZED VIO WIRE W/O REMOVABLE THIGH SUPPORT W/ REMOVABLE THIGH SUPPORT WHT WIRE

Go to component: -> Heated seats circuit, w/o memory -> FRONT PASSENGER'S SEAT CUSHION HEATING
